LED Downlights Engineered for Real Visual Comfort – UGR19, CRI 90+, Made by Jinbiao SMT

Designed for environments where visual comfort and color accuracy matter. This downlight combines a UGR <19 rating with CRI 90+ to deliver glare free, true to life illumination. Manufactured using in house Jinbiao SMT technology for consistent optical performance across every unit. Die cast aluminum housing ensures efficient thermal management and a rated lifespan of >50,000 hours. Suitable for offices, retail stores, educational facilities, and high end residential applications.

The Problem with Most LED Downlights

Walk into any office, retail store, or hotel lobby today. Chances are, you’ll see the same thing:

Harsh glare that causes eye strain by mid afternoon

Colors that look dull or washed out under artificial light

Inconsistent brightness from one fixture to the next

Early failures that turn a “simple” downlight into a maintenance headache

Most downlights are assembled from generic components. They pass basic safety tests, but they don’t solve how people actually experience light.

We built ours differently.

What Makes This LED Downlight Different

A.Glare Is Measured, Not Just “Anti Glare” by Name

We don’t just claim antiglare. We publish UGR < 19 (Unified Glare Rating) based on standard IES testing.

For commercial environments: that means staff work longer without fatigue, and customers stay longer in retail spaces.

The deeprecessed optical design eliminates the “bare bulb” look—when off, the fixture appears as a clean black diamond; when on, the light is soft but powerful.

B. Color That Actually Matters (CRI ≥ 90)

A CRI 90+ downlight isn’t just a spec sheet upgrade.

Retail: textiles, packaging, and merchandise look true to life

Offices: skin tones appear natural in video calls

Hospitality: the space feels premium, not institutional

We verify every batch with integrating sphere testing—not just sample checks.

C.Made Where We Control the LEDs

We operate our own Jinbiao SMT workshops.

That means the LED placement, soldering, and optical alignment are done inhouse, not outsourced

The result: consistent color temperature and lumen output across hundreds or thousands of fixtures—critical for large projects

Manufacturing That Backs Up the Claims

Our facility in the Mishan Advanced Equipment Manufacturing Industrial Park (Shanxi, China) follows the same standards as Guangdong Jinbiao Lighting.

Every downlight goes through:

Test	Purpose
Integrating Sphere	Verify real wattage, CRI, and lumen output
Darkroom (IES)	Confirm photometric distribution and UGR value
HighTemperature & Waterproof (IP)	Simulate extreme environments
High/Low Voltage Aging	48+ hours burnin to catch early defects

100% tested before shipping – no batch sampling, no exceptions.

Technical Profile (When Specs Actually Matter)

Parameter	Value
Power Options	9W / 12W / 15W / 20W / 25W
Input Voltage	AC 100277V (wide range, stable for global use)
CRI	≥ 90 (Ra)
UGR	< 19 (4H 8H mounting)
Color Temperature	3000K / 4000K / 5700K
Efficacy	100110 lm/W
Beam Angle	90°
Material	Diecast aluminum + PMMA frosted lens
Lifespan	>50,000 hrs (L70)
IP Rating	IP44 (front face) / IP20 (rear)
Warranty	3–5 years (projectdependent)

Where This Downlight Belongs

We’ve seen this model specified in:

Office fitouts – where UGR19 is often a mandatory requirement, not a nicetohave

Retail chains – using CRI 90+ to reduce returns caused by “color looks different at home”

Educational facilities – glare control matters for students and teachers alike

Highend residential – clients who notice the difference between a standard downlight and a precisionengineered one

Why Trust Shanxi Jinbiao Lighting?

We don’t market ourselves as just another “factory in China.”
We market ourselves as a manufacturer that solves real lighting problems.

Integrity and Innovation

We don’t overpromise. If a downlight isn’t right for your project, we’ll tell you before you order.

Customization & Project Support
